150mm dropout QS 205 5000W motorwheel , motorcycles rim with Rear QS 5000W motor , high speed and high torque for choose

QS 205 5000W High-Performance Electric Bike Motor Wheel

Transform your bike into a powerful electric vehicle with our premium 5000W BLDC in-wheel hub motor. Engineered for maximum performance and reliability.

🔥 Key Features

• Powerful Performance: 5000W rated power, 10000W peak power for incredible acceleration
• High Torque Options: Choose from 180-220 N.M max torque configurations
• Versatile Compatibility: Fits 20", 24", and 26" tires with 150mm dropout
• Premium Build: Aluminum core stator with 91% efficiency rating
• Weather Resistant: IP65 waterproof grade for all-weather riding

⚡ Technical Specifications

• Motor Type: BLDC In-Wheel Hub Motor with integrated rim
• Rated Voltage: 72V system
• Speed Options: 650-840 RPM (3.5T/4T/5T configurations)
• Brake System: Disc brake compatible
• Temperature Range: 70-120℃ operating, 150℃ peak
• Rim Width: Choose between 80MM or 100MM width

Perfect for: Electric bike conversions, high-performance e-bikes, motorcycle-style electric vehicles

Experience the thrill of silent, powerful electric propulsion with professional-grade components.

5000W
1. Motor Type: BLDC In-Wheel Hub Motor
2. Motor Design: Double Axle with Rim(integrated)
3. Matched Tire: 20inch 24inch 26inch
4. PCD: 6*44mm
5. Stator: Aluminum Core
6. Rated Power: 5000W
7. Peak Power: 10000W in few seconds
8. Rated Voltage: 72V
9. Speed:
3.5T: 840RPM
4T: 770RPM
5T: 650RPM
10. Drop-outs: 150mm
11. Max Torque:
3.5T: 180N.M
4T: 200N.M
5T: 220N.M
12. Max Efficiency: approx 91%
13. Suggest Peak Phase Current: N/A
14. Thermic Probe: KTY83/122(as default)
15. Working Temperature: 70-120℃, peak 150℃
16. Brake Type: Disc Brake
17. Hall Sensor: Dual hall set with waterproof connector
18. Phase Wire:2*5mm²Cross
19. Hall Sensor Phasing Angle: 120 degree
20. Waterproof Grade: IP65

21.Rim ：80MM or 100MM width rim for choose
